SKYLOTEC OVX TG

Oval carabiner made of lightweight metal with a compact shape and trilock closure, maximum gate opening of 17 mm

• Compactness: only 9.5 cm in length for better maneuvering space in confined areas
• Handling: curved back and oval shape for optimal gate opening and positioning
• Durability: increased cross-section for better rope sliding and reduced wear

Small-sized oval carabiner forged from lightweight alloy with a triplex sleeve. Ideal for rope work, height work, and rescue, especially where maneuvering space is limited.

Main features:

• Only 9.5 cm in length, reducing maneuvering space;
• Curved back shape allows good gate opening and improves handling;
• Oval shape for optimal positioning of devices and ropes;
• Enlarged cross-section at contact points for better rope sliding and wear resistance;
• Smooth line between the nose and the inner part of the connector facilitates insertion and removal from anchors, tools, and ropes;
• Catch-free closure.

PRODUCT

• Application areas Confined space work, Tower and mast work, Mobile platforms, Pruning, Scaffolding, Rescue, Rope access technology, Tactical access
• Fall indicator No
• Seal pack usable Not evaluated
• Maximum service life 30 years
• Minimum temperature -35 °C
• Maximum temperature 45 °C
• Swivel No
• Carabiner properties Corrosion resistant
• Open gate strength 7 kN
• Major axis strength 24 kN
• Minor axis strength 9 kN
• Carabiner type Type B (EN 12275:2013), Type B (EN 362:2004)
• ANSI standard No
• CSA standard No
• UIAA compliance Yes
• Anti-twist device No
• Carabiner category Locking carabiner
• Carabiner shape Locking carabiner
• Gate closure system Key Lock
• Gate opening 17 mm
• Material Aluminum
• Standards EN 362:2004, EN 362:2004/B, EN 12275:2013, EN 12275:2013/B, UIAA 121
• Class number E 40-21-07-12
• Customs code 76169990
• Locking system Trilock
• Color Anthracite, Orange, Silver
• Net weight 0.06 kg
• Gross weight 0.06 kg
